Scan with Antivirus

Scan files by sending them to a Clamd server.

Clamd is a de-facto open source standard for antivirus scanning. This Flow assumes a Clamd server is running and can be accessed either locally (unix socket) or remotely (tcp socket).

Once scanned, infected files can be put in a dedicated Quarantine folder. If scan fails for other reasons, files are tagged to alert that they could not be scanned properly.

Parameters

Name	Type	Default	Mandatory	Description
ServerProtocol	select, possible values: unix (unix), tcp (tcp)	tcp	true	Select protocol used to access server.
ServerAddress	text	IP:PORT	true	Select server address. Use IP:PORT for tcp or file path for unix protocol.
QuarantineFolder	text	pydiods1/QUARANTINE	true	Folder where to move files when a virus is detected.
TagInfected	text	infected	true	Tag file with this value when a virus is detected.
TagFailed	text	scan-failed	false	Tag file when virus detection failed (result is unknown).

Trigger Type

Event-based

JSON Representation

{
  "Label": "Scan with Antivirus",
  "Owner": "pydio.system.user",
  "Metadata": {
    "Description": "Scan files by sending them to a Clamd server",
    "Icon": "mdi mdi-bug",
    "TplCategory": "content-processing",
    "Usage": "Clamd is a de-facto open source standard for antivirus scanning. This Flow assumes a Clamd server is running and can be accessed\neither locally (unix socket) or remotely (tcp socket). \n\nOnce scanned, infected files can be put in a dedicated Quarantine folder. If scan fails for other reasons, files are tagged to alert that\nthey could not be scanned properly.\n"
  },
  "Custom": true,
  "EventNames": [
    "NODE_CHANGE:0",
    "NODE_CHANGE:3"
  ],
  "Actions": [
    {
      "ID": "actions.clamd.scan",
      "Label": "Send to Clamd",
      "Parameters": {
        "address": "{{.JobParameters.ServerProtocol}}://{{.JobParameters.ServerAddress}}"
      },
      "ChainedActions": [
        {
          "ID": "actions.scheduler.log-input",
          "Label": "Scan Passed",
          "ActionOutputFilter": {
            "Query": {
              "SubQueries": [
                {
                  "type_url": "type.googleapis.com/jobs.ActionOutputSingleQuery",
                  "value": "CAE="
                }
              ]
            },
            "Label": "Scan passed",
            "Description": "Check if last output string body contains a given text"
          },
          "Parameters": {
            "fieldname": "{\"@value\":\"StringBodyRegexp\"}",
            "message": "Successfully scanned \"{{base .Node.Path}}\"",
            "protocol": "{\"@value\":\"tcp\"}",
            "taskLogger": "true"
          },
          "ChainedActions": [
            {
              "ID": "actions.put-meta",
              "Label": "Tag as infected",
              "ActionOutputFilter": {
                "Query": {
                  "SubQueries": [
                    {
                      "type_url": "type.googleapis.com/jobs.ActionOutputSingleQuery",
                      "value": "EgVGT1VORA=="
                    }
                  ]
                },
                "Label": "Output contains \"FOUND\"",
                "Description": "Check if last output string body contains a given text"
              },
              "Parameters": {
                "json": "{\"usermeta-tags\":\"{{.JobParameters.TagInfected}}\"}"
              },
              "ChainedActions": [
                {
                  "ID": "actions.tree.copymove",
                  "Label": "Move to Quarantine",
                  "Parameters": {
                    "create": "true",
                    "fieldname": "{\"@value\":\"StringBodyRegexp\"}",
                    "protocol": "{\"@value\":\"tcp\"}",
                    "recursive": "false",
                    "target": "{{.JobParameters.QuarantineFolder}}",
                    "targetParent": "true",
                    "type": "move"
                  }
                },
                {
                  "ID": "actions.cmd.sendmail",
                  "Label": "Alert Owner",
                  "Bypass": true,
                  "Parameters": {
                    "fieldname": "{\"@value\":\"StringBodyRegexp\"}",
                    "message": "Virus was found on **{{.Node.Path}}**, uploaded by **{{.ContextUser.Login}}**",
                    "sender": "{\"@value\":\"smtp\"}",
                    "subject": "Virus Found",
                    "to-user": "{{.ContextUser.Login}},admin"
                  }
                }
              ]
            }
          ],
          "FailedFilterActions": [
            {
              "ID": "actions.put-meta",
              "Label": "Tag File",
              "Parameters": {
                "json": "{\"usermeta-tags\":\"{{.JobParameters.TagFailed}}\"}"
              }
            }
          ]
        }
      ]
    }
  ],
  "MaxConcurrency": 10,
  "NodeEventFilter": {
    "Query": {
      "SubQueries": [
        {
          "type_url": "type.googleapis.com/service.Query",
          "value": "CiwKHnR5cGUuZ29vZ2xlYXBpcy5jb20vdHJlZS5RdWVyeRIKOgYucHlkaW9wARAB"
        },
        {
          "type_url": "type.googleapis.com/service.Query",
          "value": "CiQKHnR5cGUuZ29vZ2xlYXBpcy5jb20vdHJlZS5RdWVyeRICMAEKJwoedHlwZS5nb29nbGVhcGlzLmNvbS90cmVlLlF1ZXJ5EgUYwKjlBBAB"
        }
      ],
      "Operation": 1
    },
    "Label": "Files \u003c 10MB"
  },
  "Parameters": [
    {
      "Name": "ServerProtocol",
      "Description": "Select protocol used to access server.",
      "Value": "tcp",
      "Mandatory": true,
      "Type": "select",
      "JsonChoices": "{\"tcp\":\"tcp\",\"unix\":\"unix\"}"
    },
    {
      "Name": "ServerAddress",
      "Description": "Select server address. Use IP:PORT for tcp or file path for unix protocol.",
      "Value": "IP:PORT",
      "Mandatory": true,
      "Type": "text"
    },
    {
      "Name": "QuarantineFolder",
      "Description": "Folder where to move files when a virus is detected.",
      "Value": "pydiods1/QUARANTINE",
      "Mandatory": true,
      "Type": "text"
    },
    {
      "Name": "TagInfected",
      "Description": "Tag file with this value when a virus is detected.",
      "Value": "infected",
      "Mandatory": true,
      "Type": "text"
    },
    {
      "Name": "TagFailed",
      "Description": "Tag file when virus detection failed (result is unknown).",
      "Value": "scan-failed",
      "Type": "text"
    }
  ]
}
